Jack H7-C - Multi-Fabric Heavy Duty Walking Foot Sewing Machine. Designed for heavy materials such as bags, cushions, leather gloves, and armchairs, this machine delivers strength and precision.
Equipped with an integrated 750W motor, it can effortlessly pierce through more than 8 layers of leather.
Presser foot lifter offers 16 adjustable levels, now fully digitalized and controlled by a stepper motor—just like the stitch length—for greater precision and ease of use.
Stitch length is precisely controlled by a stepping motor, allowing adjustments accurate to 0.1 mm. High Re-Stitch Rate: Perfect re-stitching is possible at any stitch length, with reinforcement stitches achieving a high degree of overlap
Thread guide resistance has been reduced by 30%, while stitch stability has increased by 20%, minimizing skipped stitches, material puckering, and uneven densities.
Technical Specification
| Model | Jack H7-C |
|---|---|
| Application | Multi-Fabric |
| Needle | DPx17 20-23# |
| Thread No. | 2 |
| Needle Gauge | 1-8mm |
| Presser Foot Height | Automatic / Smart Knee Lift 16mm |
| Thread Take-up Stroke | 71mm |
| Needle Bar Stroke | 37mm |
| Max Sewing Speed | 2500rpm |
| Motor Power | 750W |
| Volume | 715x310x570 |
| Weight | 40.6 / 47.84 KG |
Jack H -C Walking Foot Industrial Machine | Limited Offer
- Sewing speed up to 2500 stitches rpm
- Digital stitch length: up to 8 mm
- Thick material - leather / upholstery
- Direct Drive (motor in head)
- Double transport - lower teeth and upper rolling foot
- Underbed trimmer
- Auto presser foot lift
- Programmable start / end backtack
- Perfect movement of upper and lower layers
- Built in LED light
- Automatic Smart Knee Lift 16mm
- Guarantee 1 year
- Needle system: DPx17 Requires Needle size 20-23
Education prices available please ring the above number or email us.
Option 2 and 3 include installation and run through from our trained technicians.
1. Free - Collection from Bristol showroom
2. Free - Local delivery - (under 5 mile radius of the shop)
3. Extended local delivery - up to £50.00 - (from 5 up to 50 miles radius of shop ) - We will contact you to arrange delivery and take delivery payment.
4. National UK mainland curbside delivery only - £85.00 - NB:- Curbside = will be delivered, via courier, as close to the outside of the property as possible on a pallet. Restrictions due to pathways, steps etc will limit how close it will be delivered. This item will require a minimum 2 person handling.
All machines are assembled and pretested before despatch - For option 3 - the machine and thread stand will need to be placed or attached to the table. Instructions are provided.
